DRAWING(unit:mm):
GT3L:
GT3S:
FEATURES:
- Very short response time
- High temperature up to +300℃
- Small dimensions
- Excellent stability at high temperature
- Excellent stability at high humidity condition
APPLICATIONS:
- HVAC
- Industry
- Medical
- Consumer Electronics
- Alternative Energy
- Telecommunications
- Medical and environmental systems
OPTIONS:
- Glass bead size : Max OD1.8*7mm,Max OD1.8*4mm
- Wire material: Dumet wires (copper-clad FeNi) , available solder plated
- Wire gauge: OD0.25mm
- Wire length: 25.4±2mm
- Stock parameters: 10k3435,10k3950,10K3977
